Fortinet Firewall FG-201F
Fortinet FortiGate-201F - Hardware 18 x GE RJ45 (including 1 x MGMT port, 1 X HA port, 16 x switch ports), 8 x GE SFP slots.
100% original guarantee
Return within 30days
Free delivery on all orders
FG-201F Specification | |
Interfaces and Modules | |
GE RJ45 Ports | 16 |
GE RJ45 Management / HA | 1 / 1 |
GE SFP Slots | 8 |
10 GE SFP+ FortiLink Slots (default) | 2 |
10 GE SFP+ Slots | 2 |
USB Port | 1 |
Console Port | 1 |
Onboard Storage | 1x 480 GB SSD |
Included Transceivers | 0 |
System Performance — Enterprise Traffic Mix | |
IPS Throughput 2 | 5 Gbps |
NGFW Throughput 2, 4 | 3.5 Gbps |
Threat Protection Throughput 2, 5 | 3 Gbps |
System Performance and Capacity | |
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 27 / 27 / 11 Gbps |
Firewall Latency (64 byte, UDP) | 4.78 μs |
Firewall Throughput (Packet per Second) | 16.5 Mpps |
Concurrent Sessions (TCP) | 3 Million |
New Sessions/Second (TCP) | 280,000 |
Firewall Policies | 10,000 |
IPsec VPN Throughput (512 byte) 1 | 13 Gbps |
Gateway-to-Gateway IPsec VPN Tunnels | 2,500 |
Client-to-Gateway IPsec VPN Tunnels | 16,000 |
SSL-VPN Throughput | 2 Gbps |
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 500 |
SSL Inspection Throughput (IPS, avg. HTTPS) 3 | 4 Gbps |
SSL Inspection CPS (IPS, avg. HTTPS) 3 | 3,500 |
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 | 300,000 |
Application Control Throughput (HTTP 64K) 2 | 13 Gbps |
CAPWAP Throughput (HTTP 64K) | 20 Gbps |
Virtual Domains (Default / Maximum) | 10 / 10 |
Maximum Number of FortiSwitches Supported | 64 |
Maximum Number of FortiAPs (Total / Tunnel) | 256 / 128 |
Maximum Number of FortiTokens | 5,000 |
High Availability Configurations | Active, Active-Active, Passive, Clustering |
Dimensions and Power | |
Height x Width x Length (inches) | 1.73 x 17.01 x 13.47 |
Height x Width x Length (mm) | 44 x 432 x 342 |
Weight | 10.14 lbs (4.6 kg) |
Form Factor | Ear Mount, 1 RU |
AC Power Supply | 100–240V AC, 50/60 Hz |
Power Consumption (Average / Maximum) | 104.52 W / 121.94 W |
Current (Maximum) | 100V / 2A, 240V / 1.2A |
Heat Dissipation | 436.98 BTU/h |
Redundant Power Supplies | Yes |
Operating Environment and Certifications | |
Operating Temperature | 32–104°F (0–40°C) |
Storage Temperature | -31–158°F (-35–70°C) |
Humidity | 20–90% non-condensing |
Noise Level | 49.9 dBA |
Forced Airflow | Side to Back |
Operating Altitude | Up to 7,400 ft (2,250 m) |
Compliance | FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI |
Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN, IPv6 |
